OAK-FFC-IMX378

Buy it on Luxonis shop

../_images/imx378.jpg

Overview

The OAK-FFC-IMX378 is a carrier board for the Arducam PY011 IMX378 camera module, and is designed to be compatible with OAK-FFC-3P, OAK-FFC-4P, and DepthAI RPi HAT baseboards. A 26-pin FFC is used to carry 5V power, 4-lane MIPI, I2C, and other control signals between the this camera module and the controller baseboard.

Hardware specifications

Sensor specifications

Camera Specs

Color camera

Sensor

IMX378

DFOV / HFOV / VFOV

81° / 69° / 55°

Resolution

12MP (4032x3040)

Focus

Auto-Focus: 8cm - ∞

Max Framerate

60 FPS

F-number

2.0

Lens size

1/2.3 inch

Pixel size

1.55µm x 1.55µm

Board Layout and Dimensions

../_images/BG0249_R0M0E0_diag.jpg ../_images/BG0249_R0M0E0_dims.jpg

Key features

  • 26 pin 0.5mm FFC interconnect to baseboard

  • 30 pin interface to IMX378 camera module

  • 4-lane MIPI

  • Aux/Control signals to camera module

  • 5V power input via FFC

  • On-board power generation for camera module

  • Design files produced with Altium Designer 20

../_images/imx378_coin.jpg

Getting started

Camera module compatibility is known for the Arducam PY011 IMX378 module (and previously used Sunny A12N02A), but not tested for other modules. The FFC connector is an 0.5mm pitch, 26-pin, and bottom-contact, across which travels the 4-lane MIPI, 5V, I2C, camera clock, camera reset, and other optional control lines. 5V power is regulated down and filtered as appropriate to meet the requirements of the compact camera module and IMX378.

3D Models

  • Board STEP files here
